There are single-axis mixer and double-axis mixer, when the equipment is operating, its internal materials are in a state of weightlessness, and the materials inside can be staggered and diffused to achieve a more effective and sufficient mixing of the materials.
The maximum volume of the dual-axis non-gravity mixer can reach 4000-8000L, the dual-axis speed is 55 revolutions per minute. Compared with the single-axis mixer, the mixing volume is relatively large, suitable for the production of bulk materials with larger output, and the raw materials such as sand, cement, gypsum, fly ash, heavy calcium, ash calcium and admixtures can be fully turned evenly in about 180 seconds. The formation of the finished material to reach the specified strength, but also the use of a unique hydraulic door structure, can make the material in 10 seconds to complete the discharge, discharge residual less, and our mixer discharge port is equipped with a distributor, according to the need to control the finished material is sent to the packaging machine for bagging or through the dry powder feed screw to the bulk head for bulk.

The dual-shaft driving device adopts frequency conversion speed regulation technology, which can adjust the rotation speed according to different mixing requirements to achieve the best mixing effect.
The industrial gearbox is used instead of the traditional chain drive.
The combination of mechanical seal and pneumatic seal is adopted to eliminate the phenomenon of leakage and reduce the waste of materials.
Replaceable wear-resistant blades and packing box wear-resistant sleeves ensure the production of 300,000 tons of mortar without changing the blades.
The mixing device uses a plow knife or blade blade to make the mixing effect better and more fully.
The unloading method of the big door can shorten the unloading time and improve the efficiency, and can ensure that there is no residue and the unloading speed is fast, saving time.
The cutting and sprinkling action of the high-speed flying knife makes the mixing time shorter and the mixing accuracy higher.

Shaft end sealing device
The combination of mechanical seal and pneumatic seal is adopted to ensure that the shaft end is well sealed and no oil penetrates into the main engine during the mixing process.

Hydraulic discharge system
The hydraulic unloading system is equipped with a manual door opening device, which can be opened manually in the case of power failure.

Auxiliary arm
Assist in closing the discharge door

agitator
The two stirring axes are in relative motion, and the centrifugal force of the material is used to calculate the rotational speed of the material in the state of weightlessness, so that the material is fully integrated in the state of weightlessness, and the stirring efficiency is high

Auxiliary interlocking device
Make sure the discharge door does not leak material

Shaft end oil seal
Automatic oil injection system for the whole host automatic oil injection

Warranty service: Provide 1-2 years of whole machine warranty, some core components warranty period is longer.

Maintenance service: Free maintenance during the warranty period, paid service is provided outside the warranty period.

Technical support: Provide telephone, online customer service and other technical support channels.
