Parameter name

Parameter range

 Packaging range

10-50kg

Packaging materials

Dry powder, gypsum mortar, putty powder or other powder.

Packaging speed

≥250 packets/hour
(Depends on material flow characteristics, net packaging weight, bag permeability and other factors)

Packaging precision

±1%

Operating voltage

Three-phase AC380V

Working temperature

-10° to 50°

Relative humidity

≤90% No condensation

Impeller power of packaging machine

7.5KW

working pressure

≥0.6MPa

Air consumption of impeller packaging machine

0.01m³/min

Dust removal of requirements

Wind pressure: -0.01 ~ -0.03bar adjustable; Air volume: 2000m³/ hour
Φ100 air duct access
